本申请提供了一种高熵合金靶材制备装置,属于高熵合金靶材制备技术领域,以解决现有的制备装置不能够在重新筛分和输送至粉碎辊的位置这两种导向方式之间进行切换,而且不能够自动对尺寸较大的原料进行过滤并重新粉碎和投入筛选设备中,包括底架,所述底架的顶部固定连接有第一连接板,所述第一连接板的顶部固定连接有第二连接板,所述第一连接板的右侧固定连接有第一导向板,第一连接板的左侧固定连接有第二导向板,所述第一导向板的前后两侧固定连接有侧板。本申请能够对尺寸较大的原料进行筛除并重新粉碎,然后再次投入筛选设备中,还能够在筛除尺寸较大原料时进行导向,在重新筛分和输送至粉碎辊内这两种导向方式之间进行切换。

The present application provides a high entropy alloy target preparation device, belonging to the technical field of high entropy alloy target preparation, to solve the problem that the existing preparation device is not capable of switching between the two guiding modes of rescreening and conveying to the position of the crushing roller, and is not capable of automatically filtering and re-grinding of large size raw materials and putting into the screening equipment, including the bottom frame, the top of the bottom frame Part of the fixed connection has a first connecting plate, the top of the first connecting plate is fixed connected with a second connecting plate, the right side of the first connecting plate is fixed connected with a first guide plate, the left side of the first connecting plate is fixed connected with a second guide plate, the front and back sides of the first guiding plate are fixed connected with a side plate. This application enables the screening and re-grinding of larger raw materials and re-feeding into the screening equipment, as well as guiding the screening of larger raw materials, switching between re-screening and feeding into the grinding roller.
