名称 : 钛合金在750°C氧化100 h的TEM样品
英文名称 : TEM sample of Titanium alloy oxidized at 750 °C for 100 h
材料 : 146
委托单位 : 北京科技大学
实验单位 : 北京科技大学
实验方法 : 透射电镜观察
实验设备 : 透射电镜
实验条件 : 常温
说明 : The TEM sample of the alloy after oxidation at 750 °C for 100 h was carefully positioned at the scale/substrate interface via FIB (Figa). Since the scale of the sample oxidized at such a condition has a proper thickness and remains integrated, it is selected to be cut by FIB. A TEM bright field (BF) image of the sample is shown in Figb, consisting of the scale and the Ti matrix (i.e., the substrate). Liner elemental analysis has been done along the line with an arrowhead in Figb, the result of which is shown in Figc.
英文说明 : The TEM sample of the alloy after oxidation at 750 °C for 100 h was carefully positioned at the scale/substrate interface via FIB (Figa). Since the scale of the sample oxidized at such a condition has a proper thickness and remains integrated, it is selected to be cut by FIB. A TEM bright field (BF) image of the sample is shown in Figb, consisting of the scale and the Ti matrix (i.e., the substrate). Liner elemental analysis has been done along the line with an arrowhead in Figb, the result of which is shown in Figc.
重点项目名称 : 低成本高耐蚀钛及钛合金管材与高品质钛带制造技术开发及应用
